Key Features
· Exceptional Working Height: 9.8m maximum working height with 7.8m platform height
· Heavy-Duty Capacity: 450kg standard load capacity with 113kg extended platform rating
· Spacious Platform: Generous 2270×1130mm work area for multiple operators
· Dual AC Motor System: Powerful 24V/4.5KW drive system with 24V/3.4KW AC motor
· Extended Reach: 900mm platform extension for enhanced workspace flexibility
· Superior Mobility: Zero inner turning radius for excellent maneuverability
· Robust Construction: 2250kg machine weight ensures outstanding stability
· Industrial-Grade Components: Φ381×127mm tires and 25% gradeability
Technical Specifications
Performance Parameters
Parameter Specification
Model XT-08L
Maximum Working Height 9.8m
Platform Height 7.8m
Safe Working Load 450kg
Extended Platform Load 113kg
Lifting Speed 3-5m/min
Machine Weight 2250kg
Dimension Details
Parameter Specification
Platform Size 2270×1130mm
Overall Dimensions (L×W×H) 2390×1160×2340mm
Platform Extension 900mm
Wheelbase 1865mm
Power & Mobility
Parameter Specification
Drive System 24V/4.5KW
AC Motor 24V/3.4KW
Travel Speeds 3.5km/h (folded), 0.8km/h (elevated)
Charger System 24V
Gradeability 25%
Turning Radius 0/2.5m
Ideal Applications
· Industrial Construction: Ideal for large-scale construction and installation projects
· Manufacturing Facilities: Suitable for heavy equipment maintenance and installation
· Warehouse Operations: High-level storage maintenance in industrial settings
· Infrastructure Projects: Bridge and tunnel maintenance applications
· Commercial Construction: Large-scale interior finishing and installation work
Why Choose the XT-08L?
The XT-08L represents professional-grade access equipment with its exceptional 450kg load capacity and 9.8-meter working height. The heavy-duty construction ensures stability and durability in demanding work environments, while the advanced AC motor system provides reliable performance with reduced maintenance requirements.
Key Advantages:
· ✅ Exceptional 9.8-meter working height for extensive reach requirements
· ✅ Heavy-duty 450kg load capacity for multiple operators and equipment
· ✅ Robust 2250kg construction ensures maximum stability
· ✅ Advanced AC motor system for reliable, low-maintenance operation
· ✅ Large platform with 900mm extension for enhanced workspace
Professional solution for industrial and construction applications requiring heavy-duty performance and extended reach capabilities.
