Key Features
· Substantial Working Height: 5.8m maximum working height with 3.8m platform height
· Dual Load Capacity: 230kg standard load / 113kg extended platform capacity
· Compact Design: 1440×700mm footprint allows access through standard doorways
· AC Motor System: Energy-efficient 1.6KW lifting motor and 0.5KW drive motor
· Extended Platform: 550mm platform extension for enhanced working reach
· Dual Travel Speeds: 3.5km/h folded, 0.8km/h elevated for safe operation
· Robust Power System: 12V/80AH battery with 24V charger for extended operation
· Excellent Maneuverability: Zero inner turning radius for tight space operation
Technical Specifications
Performance Parameters
Parameter Specification
Model XT-04L
Maximum Working Height 5.8m
Platform Height 3.8m
Safe Working Load 230kg
Extended Platform Load 113kg
Lifting Speed 3-5m/min
Dimension Details
Parameter Specification
Platform Size 1300×680mm
Overall Dimensions (L×W×H) 1440×700×1860mm
Platform Extension 550mm
Wheelbase 1020mm
Power & Mobility
Parameter Specification
Lifting Motor AC 1.6KW
Drive Motor AC 0.5KW
Travel Speed (folded/elevated) 3.5km/h / 0.8km/h
Battery 12V/80AH
Gradeability 20%
Ideal Applications
· Warehouse Maintenance: Ideal for stock picking and lighting maintenance
· Retail Stores: Perfect for signage installation and ceiling repairs
· Manufacturing Facilities: Suitable for equipment maintenance and installation
· Construction Sites: Efficient for interior finishing work
· Facility Management: Versatile solution for various maintenance tasks
Why Choose the XT-04L?
The XT-04L scissor lift combines compact accessibility with reliable performance. Its unique zero inner turning radius provides exceptional maneuverability in confined spaces, while the extendable platform offers additional working reach. The AC motor system ensures smooth and efficient operation with low maintenance requirements.
Key Advantages:
· ✅ Compact size for easy access through standard doorways
· ✅ Extended platform enhances working flexibility
· ✅ Environmentally friendly electric operation
· ✅ Excellent maneuverability in tight spaces
· ✅ Low maintenance requirements with AC motor system
Perfect for businesses seeking a compact and versatile aerial work platform for indoor maintenance and construction applications.
