Key Features & Benefits
· Superior Power & Performance: Equipped with either a powerful V-twin gasoline engine or a high-torque twin-cylinder diesel engine, delivering enhanced performance for demanding loading and material handling tasks.
· Excellent Mobility & Speed: Wheeled design allows for faster travel speeds up to 5.5 km/h, enabling quick movement between job sites and efficient operation on paved surfaces.
· Optimized Hydraulic Efficiency: Advanced hydraulic system ensures responsive operation with quick cycle times – boom lifts in 4.3 seconds and bucket rolls back in just 1.3 seconds, maximizing productivity.
· Versatile Application Capability: Perfect for a wide range of tasks including digging, transporting, and loading materials in various environments, from construction sites to agricultural settings.
· Durable & Reliable Construction: Built with robust components and a sturdy frame, ensuring long-term reliability and minimal maintenance requirements even in challenging working conditions.
Technical Specifications
Feature Specification
Operating Weight 870 kg
Rated Load Capacity 250 kg
Bucket Capacity 0.1 m³
Travel Speed 0 – 5.5 km/h
System Pressure 18 Mpa
Boom Lift Time 4.3 s
Boom Lowering Time 8.8 s
Bucket Dump Time 1.9 s
Bucket Rollback Time 1.3 s
Engine Options
Gasoline (Runtong) Diesel (Kepu)
Model R740D KD292FA
Type V-Twin Gasoline, Air-Cooled Twin-Cylinder Diesel, Air-Cooled
Power Output 16.8 kW / 3600 rpm 17 kW / 3600 rpm
Fuel Consumption ≤370 g/kW·h ≤270 g/kW·h
Starting System Electric Start Electric Start
Capacity
Gasoline Model Diesel Model
Fuel Tank 15 L 7 L
Engine Oil 1.6 L 2.5 L
Hydraulic Oil Tank 26 L 20 L
Upgrade your operational efficiency with powerful performance! Contact us today to learn more about the 490 Twin-Cylinder Wheeled Skid Steer Loader and discover which engine option best suits your specific requirements. Request a personalized quotation to experience the perfect combination of power and mobility.
